Note: All load readings are taken from the bottom of the indicator.

#Anvil spring hanger catalog how to

They are removed by cutting the shipping bands shown in the figure. See a video on how to remove travel stops.įigure 1: Types of Variable Spring Hangers These stops must be removed during installation while the cold load is on the spring. Thus, hydro testing must be done with the stops in place. While these are in place, loads applied to the unit, such as hydro-testing loads, will not be transferred to the spring coil. The travel stops are painted red, and are held in place with stainless steel shipping bands, as shown in Figure 2. During assembly the coils of the variable springs are pre-compressed to the cold load position and travel stops are installed. More information on the individual types may be found in our pipe supports catalog or on our Web Site,. The primary difference between the types is in the manner in which they are supported, and thus the details of installation will be different for each type.

anvil spring hanger catalog

There are seven types of variable spring hangers, designated by the letters A-G. Piping Alignment and Pipe Strain Solutions.
